HDMI EDID Manager 4K, HDCP 2.2, HDMI 2.0, 18Mbps

CYP16297

HDMI EDID Manager 4K, HDCP 2.2, HDMI 2.0, 18Mbps

The RE-EDID-4K22 HDMI EDID Manager manipulates DVI EDID and HDMI information to a HDMI source by a connected display.

HDMI input and output with 18Gbps (6G) 4K UHD support
HDCP 1.4 and 2.2 compliant
Supports HD resolutions up to 3840×2160@60Hz (4:4:4, 8-bit) & 4096×2160@60Hz (4:4:4, 8-bit)
Supports 48-bit Deep Color up to 1080p@60Hz
Supports Four different EDID modes : Read / Write / Emulate / Bypass modes
Read Mode: Reads the TV/displays EDID information
Write Mode: Overwrites the TV/displays EDID information (TV/display needs to be able to support overwrite function)
8 unique sets of EDID settings may be stored via the learning procedure.
Emulator Mode: Allows the source device to read the selected EDID information from the units default or learnt EDID memory
Bypass Mode: Allows the source device to read the EDID information from the TV/display directly
Supports DVI sources when used with a DVI to HDMI adaptor (not supplied)
Supports CEC functionality

Features

HDMI input and output with 18Gbps (6G) 4K UHD support

HDCP 1.4 and 2.2 compliant

Supports HD resolutions up to 3840×2160@60Hz (4:4:4, 8-bit) & 4096×2160@60Hz (4:4:4, 8-bit)

Supports 48-bit Deep Color up to 1080p@60Hz

Supports Four different EDID modes : Read / Write / Emulate / Bypass modes

Read Mode: Reads the TV/displays EDID information

Write Mode: Overwrites the TV/displays EDID information (TV/display needs to be able to support overwrite function)

8 unique sets of EDID settings may be stored via the learning procedure.

Emulator Mode: Allows the source device to read the selected EDID information from the units default or learnt EDID memory

Bypass Mode: Allows the source device to read the EDID information from the TV/display directly

Product Description

The RE-EDID-4K22 HDMI EDID Manager manipulates DVI EDID and HDMI information to a HDMI source by a connected display.

The EDID contains all important information on local connectivity including video/audio supportive formats, feature support for HDMI, etc.

The RE-EDID-4K22 manager aims to simplify and bypass technical issues that arise often with video integration, commercial displays in audio/vidual and testing and home cinema. With EDID emulation & bypass modes, this device is ideal to overcome compatibility issues between screen and source, especially where integrating PC’s into an AV installation is a requirement.
