4 x 150W Low Z Power Amplifier 2U
The Inter-M DPA150Q is a four channel (4 x 150W) 100v line / Low Impedance Class D Amplifier for professional zoned public address, AV and background…
- Quad channel, 4 x 150W output
- Class-D High-efficiency, high power amplifier
- 100v/70v line amplifier / 8Ω
- Only 2U rack height
Features
- Quad channel, 4 x 150W output
- Class-D High-efficiency, high power amplifier
- 100v/70v line amplifier / 8Ω
- Only 2U rack height
- AC and DC power operation
- Switch Mode power supply
- Priority Function activated by voltage-free contact closure
- Remote Power ON/OFF Control via control input
Product Description
The Inter-M DPA150Q is a four channel (4 x 150W) 100v line / Low Impedance Class D Amplifier for professional zoned public address, AV and background music installed audio systems and rack builds.
Housed within a compact and discreet 2U high casing, this 4 x 150 watt 100v line / Low Z power amplifier offers both size and weight reduction benefits.
The DPA150Q's Class-D amplification circuitry also ensures significant efficiency improvements (typically 90% efficient compared to an average of 40% efficiency expected from conventional amplification.
Each channel also provides Dual Input capabilities, allowing a priority input signal to override the standard/normal input signal; an ideal feature to support emergency paging systems.
The ideal multi-zone amplifier as part of a PA / BGM rack build system.
