4K UHD (6G) HDMI to HDMI Repeater with EDID Management
The RE-101-4K22 HDMI to HDMI Repeater with EDID management has been designed to enhance and stabilize high bandwidth for HDMI signals, with the ability to extend a UHD 4K / HDMI / HDCP2.2 signal an additional 5m without degradation of the original signal.
- HDMI input and output with 18Gbps (600MHz) 4K UHD support
- DVI 1.0 compliant with the use of an HDMI-DVI adaptor
- HDCP 1.4 and 2.2 compliant
- Supports HD resolutions up to 3840×2160@60 Hz (4:4:4, 8-bit) & 4096×2160@60 Hz (4:4:4, 8-bit)
- Supports 48-bit Deep Color up to 1080p@60Hz and 36-bit Deep Color up to 4k@60Hz (YUV 4:2:0)
- Supports pass-through of LPCM 7.1, Bitstream and HD Bitstream audio formats
- EDID selectable between internal, external and user custom EDID
- PC based EDID management tool support via the Micro-USB port
- LED display providing an easy view of the current EDID and unit status
Features
Product Description
The RE-101-4K22 HDMI to HDMI Repeater with EDID management has been designed to enhance and stabilize high bandwidth for HDMI signals, with the ability to extend a UHD 4K / HDMI / HDCP2.2 signal an additional 5m without degradation of the original signal.
The built-in EDID supports management between configurations and ease in switching between 3 separate EDID connections; Internal, External and User.
The RE-101-4K22 also features an optional PC software which will help in creating, editing or downloading the custom-made User EDID. The simple LED design and unit toggle switch means easy use, quick switch between configurations whilst managed from EDID status information.
